This cement screw has a unique design with a tri thread on the teeth, a high low thread pattern, and a four cut diamond drill tail, making it easy to penetrate materials like concrete and enhancing chip evacuation.
Application & Usage
Thread design combined with diamond tail for effortless and efficient installation.
- Carbon steel material is hard and durable, with a hardening treatment
- Special blue coating offers corrosion resistance and longevity
- Deep threads provide excellent fastening strength
- Diamond tail easily penetrates hard materials
- Suitable for securing objects in concrete, bricks, blocks, or other masonry materials
Chipboard Screws
Screws
Uploaded 07/07/2023
|
PATTA Marketing
Specifically designed for lightweight wood panels, such as plastic composite boards. They have deeper threads, providing excellent locking capability. The tip design is also different from other screws, as it is more blunt to reduce the likelihood of the board splitting when drilling.
Technical Specifications
Available Sizes
| Diamemter (D) | Length (L) | Drill Point |
|---|---|---|
| M6.3 | 60 | Diamond |
| 75 | Diamond | |
| 80 | Diamond | |
| 90 | Diamond | |
| 100 | Diamond | |
| 125 | Diamond | |
| 140 | Diamond | |
| 160 | Diamond | |
| 180 | Diamond | |
| 200 | Diamond |
| Diamemter (D) | Length (L) | Drill Point |
|---|---|---|
| #14 | 2 - 3/8 | Diamond |
| 3 | Diamond | |
| 3 - 5/32 | Diamond | |
| 3 - 1/2 | Diamond | |
| 4 | Diamond | |
| 5 | Diamond | |
| 5 - 1/2 | Diamond | |
| 6 - 5/16 | Diamond | |
| 7 - 1/8 | Diamond | |
| 7 - 7/8 | Diamond |
